PRODUCTS - Hollow Blocks

HOLLOW BLOCKS ARE MANUFACTURED AT TS 1261 STANDARD AND THE CLASS OF EXTREMELY LIGHT.

HOLLOW BLOCKS DO NOT CONTRIBUTE TO STATIC OPERATION AND FUNCTION AS FILLLING, IT IS A1 CLASS FIREPROOF AND SECURE MATERIAL



THEY ARE USED IN ORDER TO LIGTEN APRONS ON COVERINGS THEY DO NOT BEND DURING POURING OF CONCRETE AND THEIR INTEGRITY IS NOT DISTURBED



    THEY CAN BE USED ON ALL KINDS OF REINFORCED CONCRETE BUILDINGS AND THEY INCREASE RESISTANCE TO EARTHQUAKE

 Hollow Blocks are products that provide ideal Heat and Sound Isolation on building coverings..

You can choose the appropriate hollow blocks for your requirement according to the thickness of the covering concrete on both at   the multistoried or single storey buildings. Hollow Bricks are filling materials that does not bear static load. Mould is required for the covering concrete. Thickness of hollows as changing in between 20 cm and 32,5 cm, it elevates by 2,5 cm. on all types. It ensures the ceiling to be flat and presents ease of processing and provides sound and heat insulation.

COVERED HOLLOW BLOCK
BY THE RESEARCH AND DEVELOPMENT STUDIES OF OUR COMPANY NOW HOLLOW BLOCK OF ONE SIDE BEING COVERED WITH LIGHT CONCRETE IS ALSO BEING MANUFACTURED. THIS PRODUCT IS THE PATENTED PRODUCT OF OUR COMPANY.
MANUFACTURE IS MADE FOR ALL TYPES OF HOLLOWS AND GENERALLY ONE UNIT IS PLACED TO THE BEGINNING AND END OF THE HOLLOW COVERING RANGES WHILE THE APRONS ARE BEING FURNISHED..
CONSUMPTION IS AT THE LEVEL OF %10.

PRICE LISTS

APPLICATION GUIDE




  • 20 cm Hollow Block
    Type (Ts 1261): Low Density Weight (kg): 7 Dimensions: 20*40*20 cm Bending Resistance: 150 kgf Order Code: ASM20 Thermal Conductivity Value (λh): 0,37 W/mK Flooring Height (min): 27,5 cm Density: 500 kg./m3 Units Per m2: 10
  • 22,5 cm Hollow Block
    Type (Ts 1261): Low Density Weight (kg): 8,5 Dimensions: 20*40*22,5 cm Bending Resistance: 250 kgf Order Code: ASM225 Thermal Conductivity Value (λh): 0,37 W/mK Flooring Height (min): 30 cm Density: 500 kg./m3 Units Per m2: 10
  • 25 cm Hollow Block
    Type (Ts 1261): Low Density Weight (kg): 9 Dimensions: 20*40*25 cm Bending Resistance: 250 kgf Order Code: ASM25 Thermal Conductivity Value (λh): 0,37 W/mK Flooring Height (min): 32,5 cm Density: 500 kg./m3 Units Per m2: 10
  • 27,5 cm Hollow Block
    Type (Ts 1261): Low Density Weight (kg): 9,5 Dimensions: 20*40*27,5 cm Bending Resistance: 250 kgf Order Code: ASM275 Thermal Conductivity Value (λh): 0,37 W/mK Flooring Height (min): 35 cm Density: 500 kg./m3 Units Per m2: 10
  • 30 cm Hollow Block
    Type (Ts 1261): Low Density Weight (kg): 11,5 Dimensions: 20*40*30 cm Bending Resistance: 250 kgf Order Code: ASM30 Thermal Conductivity Value (λh): 0,37 W/mK Flooring Height (min): 37,5 cm Density: 500 kg./m3 Units Per m2: 10
  • 32,5 cm Hollow Block
    Type (Ts 1261): Low Density Weight (kg): 12 Dimensions: 20*40*32,5 cm Bending Resistance: 250 kgf Order Code: ASM325 Thermal Conductivity Value (λh): 0,37 W/mK Flooring Height (min): 40 cm Density: 500 kg./m3 Units Per m2: 10
  • H.B. with Concrete Blockers

    USED FOR OBSTRUCTION OF THE CONCRETE

     PATENTING PRODUCT

    Patent Document

    30% heavier than normal blocks.


CE TSE KAS
